Features:

◆ With the advanced dual-peak or multi-peak tracking technology, when the solar panel is shadowed or part of the panel fails resulting in multiple peaks on the I-V curve, the controller is still able to accurately track the maximum power point.

◆ A built-in maximum power point tracking algorithm can significantly improve the energy utilization efficiency of photovoltaic systems, and raise the charging efficiency by 15% to 20% compared with the conventional PWM method.

◆ A combination of multiple tracking algorithms enables accurate tracking of the optimum working point on the I-V curve in an extremely short time.

◆ The product boasts an optimum MPPT tracking efficiency of up to 99.9%.

◆ Advanced digital power supply technologies raise the circuit's energy conversion efficiency to as high as 98%.

◆ Charging program options are available for different types of batteries including gel batteries, sealed batteries, open batteries, lithium batteries, etc.

◆ The controller features a limited current charging mode. When the solar panel power exceeds a certain level and the charging current is larger than the rated current, the controller will automatically lower the charging power and bring the charging current to the rated level.

◆ Instantaneous large current startup of capacitive loads is supported.

◆ Automatic recognition of battery voltage is supported.

◆ LED fault indicators and an LCD screen which can display abnormality information help users to quickly identify system faults.

◆ Historical data storage function is available, and data can be stored for up to a year.

◆ The controller is equipped with an LCD screen with which users can not only check device operating data and statuses, but also modify controller parameters.

◆ The controller supports standard Modbus protocol, fulfilling the communication needs of various occasions.

◆ The controller employs a built-in over-temperature protection mechanism. When temperature surpasses the set value, the charging current will decline in linear proportion to the
